Frequency :50 Hz
Rated AC output : 8.0 KVA (36A)
Max. AC output: 8.3 KVA (40A)
DC output V-A: 12V/8.3A
Rated voltage : 220 V
Power factor: 1
Phase: Single-phase
Voltage Regulation System: AVR
Excitation system: Controlled silicon self excitation constant voltage
Dimensions ( L x W x H): 1111 x 640 x 890 mm
Dry weight(electric): 200 KGS
Engine Model: 1100FGET
Type: 4-stroke,single-cylinder,air-cooled,direct injection diesel engine
Bore x stroke: 100 x 85 mm
Displacement: 668 cc
Starting system: Remote/ Electric Start
Rated output :14/3000 PS/RPM
Fuel tank capacity: 28L
Lube. oil capacity: 2L
Sound level db (7M): 70
Operational capacity (hr est. on 100% rated load): 10 Hrs
